202-DFNT-MCM4是ProSoft Technologies生產的一款以太網/IP到Modbus的主/從網關模塊，用于在以太網/IP網絡和Modbus RTU/ASCII設備之間建立通信橋梁。

202-DFNT-MCM4 以太網模塊圖片展示

202-DFNT-MCM4 以太網模塊視頻展示

202-DFNT-MCM4 以太網模塊詳情

模塊特點

Module characteristics

Protocol Conversion: The 202-DFNT-MCM4 module is capable of converting Modbus RTU or ASCII protocols to Ethernet/IP protocols, allowing Modbus devices to connect to Ethernet/IP based networks.

Bidirectional communication: The module can serve as both a Modbus master station and a slave station, supporting bidirectional data transmission and enabling remote device monitoring and control.

Compatibility: Compatible with Rockwell Automation PLCs (such as ControlLogix, SLC, MicroLogix, etc.) and other devices that support Ethernet/IP protocols.

Configuration flexibility: Users can set parameters, including IP address, subnet mask, Modbus address mapping, etc., through a web interface or dedicated configuration software.

High speed data transmission: Supports high-speed Ethernet connections to ensure fast data transmission between Modbus devices and Ethernet/IP networks.

Precautions for use

Network planning: Before installing the module, ensure that the network planning is reasonable, including correct IP address allocation, subnet mask setting, and gateway configuration.

Modbus device compatibility: Confirm that the Modbus devices on site are compatible with the modules, including matching parameters such as baud rate, data bits, stop bits, and parity.

Security settings: Considering network security, appropriate firewall rules and access controls should be set up to prevent unauthorized access.

Software updates: Regularly check and apply the latest software updates to maintain module performance and security.

Maintenance and monitoring: Regularly check the operational status and network performance of modules to ensure the stability of communication links and the quality of data transmission.
