ABB 3bhb030310r0001電網斷路器單元
1.產 品 資 料 介 紹：
ABB 3BHB030310R0001 是一款用于中高壓驅動系統中的電網斷路器控制單元（Grid Breaker Unit）。它主要用于管理電源與驅動設備之間的電氣連接，通過控制斷路器的合閘與分閘，實現系統啟動、運行及故障保護時的電網隔離。該產品廣泛集成于 ABB 的中壓變頻器系統（如 ACS6000）中，是整個驅動系統電源控制與保護的重要組成部分。
技術參數（簡要）
型號：3BHB030310R0001
功能類型：電網斷路控制，驅動系統電源管理
控制電壓：典型為 24V DC（具體取決于配套系統）
支持通信：與 ABB 控制板（如 PMI、GVC 等）連接，具備狀態反饋功能
系統適配：常見于 ABB ACS5000、ACS6000 系列變頻器系統
安裝方式：模塊化設計，可集成于機柜或變頻系統內部
適用電壓等級：6kV / 11kV 中壓系統（視整機配置）
應用領域
中壓變頻器系統電源管理
作為電網輸入側控制裝置，控制電源接入或切斷，保護變頻器系統的穩定運行。
適配 ABB ACS6000、ACS5000 等高壓變頻設備。
大型工業驅動系統
用于礦山、冶金、水泥、電廠等行業的高功率電機控制場合。
實現主電源的遠程控制與異常斷開保護。
自動化配電與能源管理系統
應用于高壓供電系統，實現遠程斷路、母線切換等自動控制功能。
風電與水處理等連續運行系統
用于風力發電、水泵系統中關鍵電源控制節點，提升系統可靠性與維護效率。
產品優勢
快速響應：可在毫秒級別內控制電源斷開，避免系統過載或損壞
高安全性：具備短路、過壓等保護能力，支持與系統故障檢測模塊聯動
系統兼容性強：與 ABB 多種控制模塊（如 PMI、SDCS、PEC）無縫協同
便于維護：模塊化設計，故障定位快捷，支持快速更換與現場調試
適用于惡劣環境：工業級設計標準，支持高溫、強干擾等復雜電氣環境運行
英文資料：
ABB 3BHB030310R0001 is a grid breaker control unit used in medium and high voltage drive systems. It is mainly used to manage the electrical connection between power supply and driving equipment, and to achieve grid isolation during system startup, operation, and fault protection by controlling the closing and opening of circuit breakers. This product is widely integrated into ABB's medium voltage frequency converter system (such as ACS6000) and is an important component of the power control and protection of the entire drive system.
Technical parameters (brief)
Model: 3BHB030310R0001
Function type: Power grid circuit breaker control, drive system power management
Control voltage: Typically 24V DC (depending on the supporting system)
Support communication: connected to ABB control boards (such as PMI, GVC, etc.), with status feedback function
System adaptation: commonly used in ABB ACS5000 and ACS6000 series frequency converter systems
Installation method: Modular design, can be integrated into cabinets or frequency conversion systems
Applicable voltage level: 6kV/11kV medium voltage system (depending on the overall configuration)
application area
Power Management of Medium Voltage Inverter System
As an input side control device of the power grid, it controls the connection or disconnection of the power supply to protect the stable operation of the frequency converter system.
Suitable for ABB ACS6000, ACS5000 and other high-voltage frequency conversion equipment.
Large industrial drive system
Used for high-power motor control in industries such as mining, metallurgy, cement, and power plants.
Implement remote control and abnormal disconnection protection for the main power supply.
Automated Distribution and Energy Management System
Applied to high-voltage power supply systems, it achieves automatic control functions such as remote circuit breaking and bus switching.
Continuous operation systems such as wind power and water treatment
Used as a key power control node in wind power generation and water pump systems to enhance system reliability and maintenance efficiency.
Product advantages
Quick response: can control power disconnection within milliseconds to avoid system overload or damage
High security: equipped with protection capabilities such as short circuit and overvoltage, supporting linkage with system fault detection modules
Strong system compatibility: seamless collaboration with multiple ABB control modules (such as PMI, SDCS, PEC)
Easy to maintain: modular design, quick fault location, support for quick replacement and on-site debugging
Suitable for harsh environments: Industrial grade design standards, supporting operation in complex electrical environments such as high temperatures and strong interference
