ABB 1MRK002247-BGr01 PCB卡
1.產 品 資 料 介 紹：
中文資料：
產品型號：1MRK002247-BGr01
產品名稱：PCB卡（Printed Circuit Board）
制造商：ABB
設備類別：ABB 電力系統中的繼電保護與控制裝置內部模塊
典型設備系列：REL670、RET670、REF670 等 670 系列 IED
一、功能定位
信號處理或中繼接口功能
該PCB卡可能承擔模擬/數字信號輸入輸出、通道隔離、繼電控制等輔助控制功能。
模塊化組件接口板
用作控制主板與外部設備（如斷路器、CT/VT、通信網絡）之間的中介接口。
系統連接與信號路由
將系統內部控制邏輯信號分配至其他模塊或外設，實現邏輯傳輸和信號匹配。
輔助功能板（如觸發、繼電輸出或隔離）
用于與跳閘、告警、狀態信號等相關的物理接口連接。
二、應用領域
繼電保護裝置內部擴展模塊
安裝于 ABB 670 系列設備中，用于擴展 I/O 通道或增強功能接口。
控制屏/保護屏成套系統
應用于高壓開關站的繼保成套設備中，為核心控制板提供物理接口支持。
工業電網自動化系統
用于電廠、變電站自動化場合，作為 ABB 智能電子設備的內部連接模塊。
變電站輔助控制系統
協助主控模塊完成狀態指令的傳輸與執行。
英文資料：
Product model: 1MRK002247-BGr01
Product Name: Printed Circuit Board
Manufacturer: ABB
Equipment category: Internal modules of relay protection and control devices in ABB power systems
Typical equipment series: REL670, RET670, REF670 and other 670 series IEDs
1、 Functional positioning
Signal processing or relay interface function
This PCB card may undertake auxiliary control functions such as analog/digital signal input and output, channel isolation, relay control, etc.
Modular Component Interface Board
Used as an intermediary interface between the control motherboard and external devices such as circuit breakers, CT/VT, and communication networks.
System connection and signal routing
Distribute internal control logic signals to other modules or peripherals to achieve logic transmission and signal matching.
Auxiliary function board (such as trigger, relay output, or isolation)
Used for physical interface connections related to tripping, alarms, status signals, etc.
2、 Application Fields
Internal expansion module of relay protection device
Installed in ABB 670 series equipment for expanding I/O channels or enhancing functional interfaces.
Control screen/protection screen complete system
Applied in the complete set of relay protection equipment for high-voltage switchgear, providing physical interface support for the core control board.
Industrial power grid automation system
Used as an internal connection module for ABB intelligent electronic devices in power plant and substation automation scenarios.
Substation auxiliary control system
Assist the main control module in completing the transmission and execution of status instructions.
