REL551 1MRK002480-AE線路差動保護裝置是配電、變電站和輸電線路差動保護應用的基本單元，是PANORAMA變電站自動化的一部分。
REL551 1MRK002480-AE線路差動保護裝置產品圖片展示：
REL551 1MRK002480-AE線路差動保護裝置實物產品拍攝視頻：
REL551 1MRK002480-AE線路差動保護裝置產品詳情說明：
線路差動功能包括：- 分相電流微分幅值和相位角的測量- 通過CT飽和檢測器提高穩定性- 傳輸延遲的連續補償， 能夠使用路由交換通信網絡- 數字通信信道內的轉移跳閘- 主/主設計- 用于多路連接、直接光纖或?qū)ьl線的接口? 附加保護功能，如：-相位和剩余電流函數- 斷路器故障保護&二進制信號的快速通道間通信- 電流電路監控-單極或多極跳閘? 控制指揮控制-自動重合閘?監控- 事件記錄器-干擾記錄器 | Line differential functionality comprises;- phase segregated current differentialmeasurement evaluating both magnitude and phase angle- increased stabilisation through CT saturation detector- continuous compensation of transmission delay, enabling use of routeswitched communicationnetworks- transfer trip within the digital communication channel- master/master design- interfaces for multiplexed connections,direct fibre or pilot wires? Additional protection functionality such as;-phase and residual current functions- breaker failure protection- fast interbay communication of binarysignals- current circuit supervision- single-or multi-pole tripping? Control;- command control- autoreclosing? Monitoring;- event recorder- disturbance recorder |
應用電流差動保護比較進入和離開受保護的架空線路或電纜的電流。需要一個可靠的通信設施，以便在線路末端的終端之間進行信息交換。該差動功能為輸電、輸電和配電網絡提供分相真電流差動保護。它在所有方面都是一個數字系統，用于現代數字通信系統，包括多路復用和路由交換系統。電流在每相的基礎上進行比較，避免了電流求和方法的問題，并為單極跳閘提供了相位選擇信息。
ApplicationCurrent differential protection compares thecurrents entering and leaving a protectedoverhead line or cable. A dependable communication facility is needed to allow information exchange between the terminals at theline ends.This differential function offers phase-segregated true current differential protection fortransmission, sub-transmission and distribution networks. It is in all a numerical systemfor use with modern digital communicationsystems including multiplexed and routeswitched systems. Currents are compared ona per phase basis, obviating the problem ofthe current summation approach and providing phase selection information for singlepole tripping.
