A-B 1762-L24BXB可編程控制器 是羅克韋爾自動化（Rockwell Automation）旗下的Allen-Bradley品牌的一款產品。這款控制器模塊屬于MicroLogix 1200系列，具有一系列的技術特點和功能。
A-B 1762-L24BXB可編程控制器 詳情介紹：
AB 1762-L24BXB可編程控制器是羅克韋爾自動化（Rockwell Automation）旗下的Allen-Bradley品牌的一款產品。這款控制器模塊屬于MicroLogix 1200系列，具有一系列的技術特點和功能。
首先，它具有內置電源，額定輸入電源電壓為24VDC。此外，它配有一個mini-DIN 8引腳圓形RS232連接器，這個連接器安裝在控制器的前面板上，可以用于多種通信功能，如編程、硬件配置、在線編輯以及與可視化系統的通信，如監控和數據采集（SCADA）和人機界面（HMI）。
在電源方面，這款控制器在5VDC時提供400mA的輸出電流，在24VDC時提供350mA的輸出電流，總電源使用功率為27瓦。它的設計能夠承受20ms 15A的浪涌電流，顯示了其出色的電氣性能。
在環境適應性方面，這款控制器的工作溫度范圍為+0°C至+55°C（+32°F至+131°F），儲存條件為相對濕度5-95%的-40°C至+85°C（-40°F至+185°F）的設施中。這表明它可以在廣泛的工業環境中穩定運行。
安裝方面，AB 1762-L24BXB支持DIN導軌或直接面板安裝，為用戶提供了靈活的安裝選擇。其物理尺寸為90毫米（DIN插銷打開時）或104毫米（DIN插銷關閉時）、110毫米（寬）和87毫米（深），體積適中，便于安裝和集成。
在功能方面，這款控制器具有24個I/O點，包括10個24V DC輸入項和4個快速24V DC輸入項，以及5個繼電器輸出、4個24V DC FET輸出和1個高速24V DC FET輸出。這些豐富的I/O選項使其能夠滿足各種工業自動化和控制需求。
此外，由于采用了模塊化設計，用戶可以獨立選擇I/O、端子類型和網絡接口，使得這款控制器在應用中具有高度的靈活性和可定制性。同時，其可拆卸線系統和可配置功能使得安裝、維護和故障診斷變得更加簡單和方便。
總的來說，AB 1762-L24BXB可編程控制器是一款功能強大、性能穩定、安裝方便、易于維護的工業自動化控制設備，廣泛應用于各種工業自動化和控制系統中。
A-B 1762-L24BXB可編程控制器 實物圖片：
A-B 1762-L24BXB可編程控制器 實物視頻
A-B 1762-L24BXB Programmable Controller Details Introduction:
The AB 1762-L24BXB programmable controller is a product of the Allen Bradley brand under Rockwell Automation. This controller module belongs to the MicroLogix 1200 series and has a series of technical features and functions.
Firstly, it has a built-in power supply with a rated input power voltage of 24VDC. In addition, it is equipped with a mini DIN 8-pin circular RS232 connector, which is installed on the front panel of the controller and can be used for various communication functions such as programming, hardware configuration, online editing, and communication with visualization systems such as SCADA and HMI.
In terms of power supply, this controller provides an output current of 400mA at 5VDC and 350mA at 24VDC, with a total power consumption of 27 watts. Its design can withstand a surge current of 20ms 15A, demonstrating its excellent electrical performance.
In terms of environmental adaptability, the operating temperature range of this controller is+0 ° C to+55 ° C (+32 ° F to+131 ° F), and the storage conditions are -40 ° C to+85 ° C (-40 ° F to+185 ° F) in facilities with relative humidity of 5-95%. This indicates that it can operate stably in a wide range of industrial environments.
In terms of installation, AB 1762-L24BXB supports DIN rail or direct panel installation, providing users with flexible installation options. Its physical dimensions are 90 millimeters (when the DIN pin is open) or 104 millimeters (when the DIN pin is closed), 110 millimeters (wide), and 87 millimeters (deep), with a moderate volume for easy installation and integration.
In terms of functionality, this controller has 24 I/O points, including 10 24V DC input items and 4 fast 24V DC input items, as well as 5 relay outputs, 4 24V DC FET outputs, and 1 high-speed 24V DC FET output. These rich I/O options enable it to meet various industrial automation and control needs.
In addition, due to its modular design, users can independently choose I/O, terminal type, and network interface, making this controller highly flexible and customizable in applications. Meanwhile, its detachable cable system and configurable features make installation, maintenance, and fault diagnosis simpler and more convenient.
Overall, the AB 1762-L24BXB programmable controller is a powerful, stable, easy to install, and easy to maintain industrial automation control equipment, widely used in various industrial automation and control systems.
